We make it easy to connect and configure your temperature controller
The Red Lion series of controllers are not only among the most affordable, but because we ship all of them pre-configured by ECS experts, they are among the simplest to connect and keep your extruder running. Check out our simple wiring instructions below, or to learn more about installing and configuring your PXU temperature controller, just click the appropriate link the video or downloadable document.
PXU16RRAC WIRING
Download Data Sheet- Power Conections (1, 2)
- Full PID Cool Control (3, 4)
- Full PID Heat Control (5, 6)
- Dual Alarm Relays (7, 8, 9)
- Universal Inputs (10, 11, 12)
- Digital Inputs (13, 14)
- Digital Inputs (15, 16)
- RS-485 Digital Communications (17, 18)
PXU16LRAC WIRING
Download Data Sheet- Power Conections (1, 2)
- Full PID Cool Control (3, 4)
- Full PID Heat Control (5, 6)
- Dual Alarm Relays (7, 8, 9)
- Universal Inputs (10, 11, 12)
- Digital Inputs (13, 14)
- Digital Inputs (15, 16)
- RS-485 Digital Communications (17, 18)
PXU-18
PXU18RRAC WIRING
Download Data Sheet- Power Conections (1, 2)
- Full PID Cool Control (3, 4)
- Full PID Heat Control (5, 6)
- Dual Alarm Relays (7, 8, 9)
- Universal Inputs (10, 11, 12)
- Digital Inputs (13, 14)
- Digital Inputs (15, 16)
- RS-485 Digital Communications (17, 18)
PXU18LRAC WIRING
Download Data Sheet- Power Conections (1, 2)
- Full PID Cool Control (3, 4)
- Full PID Heat Control (5, 6)
- Dual Alarm Relays (7, 8, 9)
- Universal Inputs (10, 11, 12)
- Digital Inputs (13, 14)
- Digital Inputs (15, 16)
- RS-485 Digital Communications (17, 18)
